Mechanical
DimensionsØ220 x 48 mm (Ø8.66 x 1.89")
WeightWithout mount: 800 g (1.76 lb)
With mount: 930 g (2.05 lb)
Enclosure materialPolycarbonate
Mount materialStainless steel (SUS304)
WeatherproofingIP54
Hardware
Networking interface(1) GbE RJ45 port
Management interfaceEthernet
Bluetooth
Power methodPoE+, passive PoE (48V)
Power supplyUniFi PoE switch
48V, 0.5A PoE adapter (Not included)
Supported voltage range44—57V DC
Max. power consumption18.5W
Max. TX power
2.4 GHz
5 GHz
26 dBm
26 dBm
MIMO
2.4 GHz
5 GHz
4 x 4
4 x 4
Throughput rate
2.4 GHz
5 GHz
600 Mbps
2400 Mbps
Antenna gain
2.4 GHz
5 GHz
4 dBi
5.5 dBi
LEDsWhite/blue
ButtonFactory reset
MountingWall/ceiling (Included)
Operating temperature-30 to 60° C (-22 to 140° F)
Operating humidity5 to 95% noncondensing
CertificationsCE, FCC, IC
Software
WiFi standards802.11a/b/g
WiFi 4/WiFi 5/WiFi 6
Wireless securityWPA-PSK, WPA-Enterprise (WPA/WPA2/WPA3
BSSID8 per radio
VLAN802.1Q
Advanced QoSPer-user rate limiting
Guest traffic isolationSupported
Concurrent clients350+
Supported Data Rates
802.11a6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11b1, 2, 5.5, 11 Mbps
802.11g6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11n (WiFi 4)6.5 Mbps to 600 Mbps (MCS0 - MCS31, HT 20/40)
802.11ac (WiFi 5)6.5 Mbps to 1.7 Gbps (MCS0 - MCS9 NSS1/2/3/4, VHT 20/40/80/160)
802.11ax (WiFi 6)7.3 Mbps to 2.4 Gbps (MCS0 - MCS11 NSS1/2/3/4, HE 20/40/80/160)
Application Requirements
UniFi NetworkVersion 6.0.34 and later
UniFi is a versatile ecosystem comprising wireless access points, switches, routers, controller devices, VoIP phones, and access control products suitable for both corporate and home networks.
